| 5G MOBILE MIMO ANTENNA |
| Frequency range |
617 – 960/ 1710 – 2690/ 2900 – 4200 MHz |
| Polarization |
Linear |
| Gain |
4.0 dBi |
| V.S.W.R |
≤3.0 |
| Impedance |
50 Ω |
| Connector type and count |
4x SMA Male |
| GNSS ANTENNA |
| Frequency range |
1164-1300/ 1559-1610 MHz |
| Polarization |
RHCP |
| Supply voltage |
3 – 12 VDC |
| LNA Gain |
40 ± 2 dB |
| V.S.W.R |
≤2.0 |
| Impedance |
50 Ω |
| Current Consumption |
≤60 mA |
| Connector type and count |
SMA Male |
| WIFI MIMO ANTENNA |
| Frequency range |
2400 – 2483.5/ 4900 – 5925 MHz |
| Polarization |
Linear |
| Gain |
4.0 dBi |
| V.S.W.R |
≤2.5 |
| Impedance |
50 Ω |
| Connector type and count |
2x RP SMA Male |
| MECHANICAL ENVIRONMENTAL |
| Mounting method |
Screw |
| Radome ingress projection rating |
IP67 (exclude cable outlet) |
| Radome material |
UV-Resistant ABS/PC |
| Weight |
960 ± 30 g |
| Housing dimensions |
189 x 182 x 85 mm |
| Cable |
7 x LMR100, 3000 mm |
| Recomended mounting dimensions |
Hole o28 mm, panel thickness MAX 8 mm |
| Operating temperature |
-40 °C – +85 °C |
| RoHS Compliant |
✓ |
