| GENERAL |
| Input voltage |
100 – 240 VAC |
| Input frequency |
50/60 Hz |
| Input current |
2.5 A |
| Input connector |
EU (Type C) |
| Output voltage |
50 VDC |
| Output current |
2.6 A |
| Output connector |
2-PIN, with cord end terminals |
| Weight |
500 g |
| ADDITIONAL |
| Input voltage absolute maximum rating |
90 – 264 VAC |
| Input frequency absolute maximum rating |
47 – 63 Hz |
| Maximum input inrush current |
50 A |
| Output voltage absolute maximum rating |
47.5 – 52.5 VDC |
| Short circuit protection |
✓ |
| HIPOT (dielectric withstand test) |
Primary to Secondary – 4242 VDC |
| 50000 h MTBF |
50000 h |
| PSU efficiency standard |
DoE Level VI |
