| HARDWARE |
| Mobile |
4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps |
| CPU |
Mediatek, 580 MHz, MIPS 24KEc |
| RAM |
128 MB, DDR2 |
| Storage |
16 MB, SPI Flash |
| Powering options |
4-pin industrial DC power socket, 9 – 30 VDC |
| SIM |
1 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V, external SIM holder |
| eSIM™ |
Consumer type eSIM™, profile download and removal operations, up to 7 eSIM™ profiles |
| TPM |
Identification and authentication module, TPM 2.0 standard |
| Antenna connectors |
2 x SMA for LTE, 1 x RP-SMA for Wi-Fi antenna connectors |
| Ethernet |
2 x RJ45 ports, 10/100 Mbps |
| Wi-Fi |
IEEE 802.11b/g/n, Access Point (AP), Station (STA) |
| Inputs/Outputs |
1 x Digital Input, 0 – 6 V detected as logic low, 8 – 30 V detected as logic high, 1 x Digital Output, Open collector output, max output 30 V, 300 mA |
| Status LEDs |
3 x Connection type status LEDs, 5 x Connection strength LEDs, 2 x LAN status LEDs, 1 x Power LED |
| Operating temperature |
-40 °C to 75 °C |
| Housing |
Aluminum housing, plastic panels |
| Dimensions (W x H x D) |
83 x 25 x 74 mm |
| Weight |
130 g |
| SOFTWARE |
| Operating system |
RutOS (OpenWrt based Linux OS) |
| Mobile features |
eSIM, Status, SMS, USSD, Black/White list, Multiple PDN, Band management, SIM idle protection service, APN, Bridge, Passthrough |
| Network features |
VoIP passthrough support, Connection monitoring, Firewall, Firewall status page, Ports management, Network topology, Hotspot, DHCP, QoS / Smart Queue Management (SQM), DDNS, DNS over HTTPS, Network backup, Load balancing, SSHFS |
| Security |
Authentication, Firewall, Attack prevention, VLAN, Mobile quota control, WEB filter, Access control, TPM, SSL certificate generation |
| VPN and tunneling |
OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc |
| Monitoring and Management |
WEB UI, FOTA, SSH, SMS, Call, Email, TR-069, MQTT, SNMP, JSON-RPC, RMS |
| Cloud solutions |
RMS, Cloud of Things, ThingWorx, Cumulocity, Azure IoT Hub |
| Services |
OPC UA, Modbus, Data to Server, Modbus MQTT Gateway, DNP3, DLMS, API |
