| HARDWARE |
| Mobile |
4G (LTE) – Cat 6 up to 300 Mbps (DL) / 50 Mbps (UL), 3G up to 42 Mbps (DL) |
| CPU |
Mediatek, 580 MHz, MIPS 24KEc |
| RAM |
128MB, DDR2 |
| FLASH storage |
16MB serial NOR flash |
| Powering options |
4-pin industrial DC power socket, 9 – 30 VDC |
| SIM |
1 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, external SIM holder |
| Antenna connectors |
2 x SMA for Mobile, 2 x RP-SMA for Wi-Fi |
| Ethernet |
2 x RJ45 ports, 10/100 Mbps |
| WiFi |
802.11 b/g/n, 2×2 MIMO, Access Point (AP), Station (STA) |
| Inputs/Outputs |
2 x Digital Input, 2 x Digital Output on 4-pin power connector |
| Status LEDs |
2 x Mobile connection type, 3 x Mobile connection strength, 2 x ETH status, 1 x Power |
| Operating temperature |
-40 °C to 75 °C |
| Housing |
Aluminium housing |
| Dimensions (W x H x D) |
93.2 x 100 x 30 mm |
| Weight |
243 g |
| SOFTWARE |
| Operating system |
RutOS (OpenWrt based Linux OS) |
| Mobile features |
Multiple PDN, Auto APN, Band lock, Operator black/white list, Data/SMS limits |
| Network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
| Network |
Failover (Network backup), VLAN, QoS, Load Balancing |
| VPN and tunneling |
OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, Tailscale |
| Monitoring and Management |
WEB UI, CLI, SSH, CALL, SMS,TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS |
| Connection monitoring |
Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection |
| Cloud solutions |
RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx |
| SMS features |
SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
| Services |
DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP |
