| PARAMETER |
RATED VALUE |
| Single output power |
20 W |
| Input voltage range |
85 – 264 VAC 47 – 63 Hz |
| DC output voltage |
12 V |
| DC output current |
0 – 1.67 A |
| Output ripple and noise |
120 mVp-p |
| Line regulation |
±1 % |
| Load regulation |
±1 % |
| Efficiency |
80% |
| Adjustable range for DC voltage |
±1 % |
| Inrush current |
Cold start current 20 A / 115 VAC; 40 A / 230 VAC |
| Overload protection |
105 % – 160 % cut off the output, automatic recovery |
| Over voltage protection |
120 % – 140 % shut down O/P voltage, off / on cycle required for recovery |
| Setup, rise, hold up time |
500 ms; 30 ms / 230 VAC at full load; 1000 ms; 30 ms / 115 VAC at full load |
| Withstand voltage |
I/P-O/P: 1.5 kV; I/P-FG: 1.5 kV; O/P-FG: 0.5 kV 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG: 500 VDC / 1000 M? |
| Working temperature |
-10 °C – +50 °C |
| Mounting options |
35 mm DIN Rail |
| Dimensions |
22.5 x 90 x 100 mm |
| Weight |
190 g |
