| HARDWARE |
| Mobile |
4G/LTE (Cat 4), 3G, 2G |
| CPU |
Mediatek, 580 MHz, MIPS 24KEc |
| Storage |
16 MB Flash |
| Memory |
128 MB RAM |
| Powering option |
4pin power socket, 9-30 VDC |
| SIM |
1 x External SIM holder (2FF) |
| Antenna connectors |
2 x SMA for mobile, 1 x RP-SMA for WiFi |
| Ethernet |
2 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 1 x LAN |
| WiFi |
IEEE 802.11b/g/n, Access point (AP), Station (STA) |
| Inputs/Outputs |
On 4pin socket: 1 x Digital input, 1 x Digital open collector output |
| Status LEDs |
3 x Connection type, 5 x Signal strength, 2 x Ethernet, 1 x Power |
| Operating temperature |
-40 °C to 75 °C |
| Housing |
Aluminium housing with DIN rail mounting option, plastic panels |
| Dimensions (W x H x D) |
83 x 25 x 74 mm |
| Weight |
125 g |
| SOFTWARE |
| Operating system |
RutOS (OpenWrt based Linux OS) |
| Mobile features |
Auto APN, Band lock |
| Network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, PPPo, EDHCP, Telnet |
| Network |
Failover (Network backup), VLAN, QoS, Load Balancing |
| Security |
DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), Port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
| VPN and tunneling |
OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard |
| Monitoring and Management |
WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS |
| Connection monitoring |
Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection |
| Cloud solutions |
RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx |
| SMS features |
SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, |
| Services |
DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Traffic Logging |
